Stainless Steel Radiators

Usage
Long-Lasting Usage and Superior Quality

Options
Different Length and Connection Options

Efficiency
High Efficiency and High Thermal Power

Warmhaus Stainless Steel Radiators Series will set new standards for your home.Designed with the inspiration from nature’s unlimited power and perfection.

For All Types:
Height: 600/826/1120/1200/1535/1800mm
Width: 295/326/354/413/472/500/590/600/800/826/1000/1003/1120/1180/1200/1535mm
Test Pressure: 13 bar
Max. Operating Pressure: 10 bar
Max Water Temperature: 110°C
Warranty: 10 Years
Number of Connections: 4x and 6x DIN G ½
Pipe Diameter: 33mm bend
Maximum Sheet Metal Usage
High Corrosion Resistance
Chrome option
High Thermal Efficiency
Elegant Design
Practical Installation
Extensive Product Range
Water Capacity: 6.8 liters

Product Compare

Product Information Form

TECHNICAL DETAILS
USER MANUALS & DOCUMENTS

PRODUCT CODE	HEIGHT (mm)	WIDTH (mm)	c/c (mm)	W/C (mm)	BTU/DT50	BTU/DT60
S35	1800	295	295	63-78	2610	3132
S35	1800	354	354	63-78	3654	4385
S35	1800	413	413	63-78	4100	4920
S35	1800	472	472	63-78	5050	6060
S61	600	590	590	63-78	1760	2112
S61	600	826	826	63-78	2464	2957
S61	600	1003	1003	63-78	2992	3590
S61	600	1180	1180	63-78	3520	4224
