EfficiencyEnerwa Plus, with its wide capacity range, offers tailor-made solutions for different requirements. Enerwa Plus ensures comfort, safety, and efficient combustion with the "Smart Gas" technology.
| TECHNICAL DATA | UNIT | Enerwa 24/31 Enerwa Plus 24/31 | Enerwa 28/35 Enerwa Plus 28/35 | Enerwa 33/39 Enerwa Plus 33/39 | Enerwa Plus 42/40 | Enerwa Plus 45/43 | |||||
| Gas Circuit / Gas Type | NG / G20 | LPG / G31 | NG / G20 | LPG / G31 | NG / G20 | LPG / G31 | NG / G20 | LPG / G31 | NG / G20 | LPG / G31 | |
| Gas Supply Pressure | mbar | 20 | 37 | 20 | 37 | 20 | 37 | 20 | 37 | 20 | 37 |
| Gas Consumption at Minimum / Maximum | m³/h | 0.37 / 2.38 | 0.11 / 0.92 | 0.40 / 3.05 | 0.14 / 1.18 | 0.43 / 3.40 | 0.17 / 1.3 | 0.7 / 4.0 | 0.3 / 1.6 | 0.7 / 4.2 | 0.3 / 1.7 |
| Seasonal Space Heating Energy Class / Efficiency (ŋs) | % | A / 92 | A / 92 | A / 92 | A / 92 | A / 91 | A / 92 | A / 91 | |||
| Useful efficiency at rated heat output and high temperature regime(2) (ŋ4) | % | 87,6 | 87,7 | 88,0 | 88,6 | 88,2 | 88,0 | 87,4 | 87,4 | 87,4 | 87,4 |
| Useful efficiency at 30% of rated heat output and low temperature regime(1) (ŋ1) | % | 97,5 | 97,7 | 96,8 | 96,9 | 96,9 | 96,6 | 96,6 | 96,6 | 96,6 | 96,6 |
| Radiator Circuit / Temperature Selection Range High / Low | °C | 25 - 80 / 25 - 47 | |||||||||
| Useful heat output at rated heat output and high temperature regime (2) (P4) | kW | 23,7 | 23,7 | 28 | 28 | 33,02 | 33,02 | 38,2 | 38,2 | 41,4 | 41,3 |
| Useful heat output at 30% of rated heat output and low temperature regime (1) (P1) | kW | 4,34 | 4,4 | 4,97 | 4,85 | 5,72 | 6,09 | 7,91 | 7,91 | 7,91 | 7,91 |
| (50/30 °C) Efficiency at Minimum / Maximum Heat Output Pn | kW | 3.6 / 25 | 2.9 / 25 | 3.9 / 30 | 3.9 / 30 | 3.6 / 35.5 | 2.9 / 25 | 7.6 / 42 | 7.5 / 42 | 7.6 / 45 | 7.5 / 44 |
| Operating Pressure (Minimum / Maksimum) | bar | 0.5 / 3 | |||||||||
| Expansion Vessel | liter | 8 | 10 | 10 | 12 | 12 | |||||
| Maximum Pump Pressure (Q = 0 m³/h) | mH2O | 6,2 | 7,6 | 7,6 | 7,6 | 8 | |||||
| Maximum Pump Flow Rate | l/h | 2300 (H = 0.8 mH2O) | 2500 (H = 0.4 mH2O) | 2500 (H = 0.4 mH2O) | 2300 (H = 0.4 mH2O) | 2800 (H = 0.8 mH2O) | |||||
| Domestic Hot Water Circuit / Temperature Adjustment Range | °C | 35 - 60 | |||||||||
| Water Heating Energy Efficiency Class / Declared Load Profile | A / L | A / XL | A / XL | A / XL | A / XL | A / XXL | A / XL | A / XL | A / XL | A / XL | |
| Water Heating Energy Efficiency | % | 81 | 84 | 83 | 84 | 82 | 81 | 81 | |||
| Maximum DHW Heat Input (Minimum / Maximum) | kW | 3.5 / 31.2 | 3.75 / 35 | 4.35 / 38.8 | 7.2 / 39.5 | 7.2 / 42.5 | |||||
| Modulation Range | 1/10 (11% - %100) | 1/10 (11% - %100) | 1/10 (11% - %100) | 1/5 (18% - %100) | 1/6 (17% - %100) | ||||||
| Domestic Hot Water flow rate (Δt: 30 °C) (Minimum / Maximum) | l/min | 1.5 / 15 | 1.5 / 17 | 1.5 / 19 | 1.5 / 18 | 1.5 / 20 | |||||
| DHW Water Pressure (Minimum / Maximum) | bar | 0.5 / 10 | |||||||||
| Electricity Circuit / Electricity Supply / Protection Index | [230 V +%10; -%15] / IP X 5D | ||||||||||
| Electricity Consumption (Min./Max.) | Watt | 95 / 55 | 104 / 60 | 115 / 65 | 149 / 90 | 154 / 90 | |||||
| Exhaust Gas Circuit | NG | LPG | NG | LPG | NG | LPG | NG | LPG | NG | LPG | |
| (80/60 °C) Exhaust gas temperature (Minimum / Maximum) | °C | 69 / 71 | 60 / 70 | 61/ 66 | 58 / 65 | 57 / 62 | 58 / 67 | 60 / 65 | 54 / 66 | 61 / 66 | 55 / 67 |
| (50/30 °C) Exhaust gas temperature (Minimum / Maximum) | °C | 49 / 51 | 47 / 51 | 45 / 45 | 43 / 45 | 47 / 44 | 49 / 49 | 34 / 42 | 34 / 43 | 35 / 43 | 35 / 44 |
| Weighted Value of NOX (GCV) / NOX Class: 6 | mg/kWh | 20 | 31 | 41 | 49 | 34 | 53 | 25 | 50 | 27 | 53 |
| Maximum Flue Lenght (Ø60/100 mm) [Horizontal* / (Vertical*] | m | 10 / 11 | 10 / 11 | 10 / 11 | 10 / 11 | 10 / 11 | |||||
| Type | C13. C33. C53. C63. C83. C93. C103. B23. B23P. B33 | C13. C33. C43. C53. C63. C83. B23. B23P | |||||||||
| General / Dimensions H x W X D | mm | 725 x 420 x 288 [Volume < 87.7 Liter] | 725 x 420 x 385 [Volume < 117.2 Liter] | ||||||||
| Sound Level | dB (A) | 52 | 54 | 50 | 58 | 58 | |||||
| Net Weight / Packed Device Weight | kg | 33.5 / 34.7 | 34.7 / 35.9 | 35.5 / 36.7 | 37.5 / 39.5 | 38 / 40 | |||||
| (1) Low temperature means for condensing boilers 30 °C, for low temperature boilers 37 °C and for other heaters 50 °C return temperature (at heater inlet). (2) High temperature regime means 60 °C return temperature at heater inlet and 80 °C feed temperature at heater outlet. (*) At the maximum flue distance, the flue length should be reduced by 1 meter for every 90° bend and 0.5 meter for every 45° bend. |
|||||||||||
The Gas Adaptive Technology automatically detects gas quality and prevents improper combustion, ensuring safety. Proper combustion maximizes energy efficiency, utilizing the full potential of the gas.
The use of wide-channel, seamless, single-coil stainless steel domestic hot water heat exchangers ensures a long lifespan.
With a wide modulation range of 1:7, it can reduce its power, allowing you to adjust its capacity according to your needs and save both gas and electricity.
By selecting the pre-heating parameter in your combi, the waiting time for hot water usage is minimized.
With a hot water capacity of up to 15 liters per minute, it allows you to simultaneously use hot water from two taps.
Featuring brass and composite components that are resistant to thermal stresses and corrosion, ensuring a long lifespan and years of trouble-free use.
Illuminated, large information screen that allows for control of heating, hot water, pressure, and adjustments.
Operates very quietly thanks to high level of insulation.
Achieving the best class level, which is level 6, for NOx as stipulated by the ErP Directive, helps reduce air pollution by lowering harmful NOx emissions.
High Protection System/bypass circuit and prevents the pump from overworking
